Revolution AR-01 Disc Brake Hubs

Revolution AR-01 Disc Brake Hubs

Regular price$399.00
Shipping calculated at checkout.

Main Features

  • Full complement of NTN LLB bearings for smoothness and reliability
  • Industry-standard bearing sizes mean easy maintainance and replacement.
  • 60T engagement with 5 pawls for rapid responsiveness and power transfer.
  • Weighs just 310g (Shimano freehub) - Comparable to the DT Swiss 240 (304g)
  • Compatible with both Thru Axle (100/142) and Quick Release (100/135), with 15mm Thru Axle for Reach Mini Velos



Weight: 310g/pair (Shimano)
Spoke Count: 24/24
Spoke Type: Straightpull
Spacing: 100/142mm (Thru-Axle) and 100/135mm (QR)
Thru-Axle type: 12mm
Engagement Count: 60
Pawls: 5
Bearings: NTN LLB
Front bearings: 6803 x2
Rear bearings: 6803 x1, 6903 x1, 6802 x2


Hub dimensions for wheelbuilders


Singapore orders
Pickup from our location is best - Sometimes, bikes need to be fitted to you, and wheels need to be installed properly to perform their best. We are happy to assist with that, and are best able to do so with all our tools at our disposal.​

Delivery of items is possible, and a fee will be charged if you choose this option.

International Orders
Off-the-shelf items (like wheels) will be shipped as soon as practicable. In general, we expect to ship wheels within 2-3 business days if they are in stock (ZENITH, POLARIS, Defiant carbon track wheels, Adamant Alloy wheels). Most of the required time is to get the decals prepared in your preferred color and apply them.

Custom orders like the Bolt/Intrepid mini velo and custom wheel builds will require a longer lead time of about 2 weeks to 1 month, as some parts need to be ordered and fitted. Please contact us and we will discuss the details with you.

All orders will be shipped by UPS Worldwide, except where another arrangement is required.
